ISO 分類 分組 代號 ISO Code |
牌號 Grade | 物理力學性能 Physical and Mechanical properties |
推薦用途 Applications recommended | ||
密度 Density G/cm | 硬度 Hardness HRA(HV) | 抗彎強度 TRS Mpa | |||
|
YG6X
|
14.9 |
92 |
1800 | 可用于應用不大的條件下，拉制直徑0.6mm以下的鋼絲，有色金屬線材或棒材模。 It can used to make steel wire,non-ferrous metal wire or bar material with less than 6.0mm diameter |
YG6 |
YG6 |
14.9 |
90.5 |
2000 | 可用于較大應用條件下，拉制直徑20mm以下的鋼絲，有色金屬及合金棒材，也可用于拉制直徑10mm以下的管材。 It can be used for steel wire,non-ferrous metal and alloy bars under 20mm diameter,and can also be used for drawing pipes with diameter of less than 10mm. |
|
YG8 |
14.7 |
90 |
2200 | 可用于鋼、有色金屬及合金棒材和管材的拉絲，也可用于制造機械零件、工具及易損零件。 Can be used in steel,non-ferrous metal and alloy bars and pipes,also can be used in manufacturing machinery parts,tools and vulnerable parts. |
YG8.2 |
YG8.2 |
14.6 |
89 |
2000 | |
YG8L |
YG8L |
14.6 |
89 |
2000 | |
YG11 |
YG11 |
14.4 |
88.5 |
2300 | 可用于高壓縮率鋼棒和鋼管拉伸，在較大應力下工作的頂錘、穿孔及沖壓模具。 It can be used for high compression steel rod and steel pipe drawing,and the top hammer,perforation and stamping die of working under greater stress. |
YG15 |
YG15 |
14.0 |
87 |
2600 | |
YL50 |
YL50 |
14.4 |
87 |
2600 | |
YG20 |
YG20 |
13.6 |
85 |
2800 | 可用于制沖壓模具、如沖壓手表零件等，沖壓電池殼，牙膏皮的模具，小尺寸的鋼球、螺釘。螺帽等的沖壓模具等。 It can be used for stamping die,such as punching watch parts,stamping battery shell,tooth paste mould,small size steel ball,screw,nut,etc. |
YG20C |
YG20C |
13.6 |
83.5 |
2800 |
可用于標準件，軸承，工具等行業用的冷鍛，冷沖，冷壓模具，彈頭和彈殼的沖壓模具。 It can be used in standard parts,bearings,tools and other industries for cold forging,cold pressing,clod pressing,cold pressing mould,warhead and shell stamping die. |
TL40.5 |
TL40.5 |
13.3 |
82 |
3000 | |
